Ideal for Temporary Backup for DIN Mounted Electronics​
Overview
Features
Specs
Docs
Numbers
Overview
The 4.5AH backup battery pack is a compact sealed battery unit ideally suited for 48VDC UPS applications, or other industrial applications where battery reserve power is required.
Backup batteries are used with RLH AC/DC DIN mount power supplies and charge controller to provide backup power in the event of an AC outage.
Each battery pack has two leakproof and maintenance free internal lead/acid batteries. The battery pack has a life expectancy of 5 years in standby service, or more than 250 cycles at 100% discharge in cycle service. Excessive hot or cold temperatures will decrease battery life.
The battery pack is DIN rail mounted, and includes 2 DIN rail clips for stability. Use the DIN rail to mount the battery to a wall or equipment rack. The quick release DIN brackets allow for easy removal of the battery pack for servicing or replacement.
Battery packs connect to a battery charge controller via screw down terminals on the bottom. An externally replaceable fuse is included to protect the battery circuit.
Depleted and/or defective batteries are field replaceable by qualified personnel. Refer to ordering information for replacement batteries.
Features
- Includes Dual DIN clips for extra stability
- Compact design
- Durable ABS thermoplastic with gasket sealed cover
- Easy to access screw down terminals
- Ideally suited for 24VDC UPS applications
- External replaceable fuse
- Includes sealed, maintenance free, Lead acid battery with AGM technology
- Up to 5 years of stand by service
Specs
Battery Pack Construction:
Durable ABS thermoplastic with gasket sealed cover
Dimensions:
L 9.5in. x D 4.5in. x H 6.5 (W 241mm x D 114mm x H 165mm)
Mounting:
DIN Clip for T35 DIN Rail
Power Connection:
Screw down power terminals
Weight:
9 lbs. (4.1kg)
Internal Batteries:
Quantity 2, 12VDC, 4.5Ah
Battery Type:
Lead acid deep cycle AGM, spill proof, maintenance free
Nominal Voltage:
24VDC
Capacity:
4.5 Ah @ 25ËšC
Fuse:
6A, user replaceable
Operating Temperature Range:
Discharge -15ËšC ~ 50ËšC (5ËšF ~ 122ËšF)
Charge -15ËšC ~ 40ËšC (5ËšF ~ 104ËšF)
Storage -15ËšC ~ 40ËšC (5ËšF ~ 104ËšF)
Charging Voltage:
27.0 to 27.6VDC/unit average at 25ËšC
Cycle Use 14.7V ±0.3V @25˚C (77˚F)
Maximum Charging Current Limit:
1.35A
Self Discharge:
Less than 10% after 90 days, Battery pack can be stored for up to 6 months at 25ËšC (77ËšF)
Batteries must be charged before using
* Extreme temperatures will reduce storage time
Docs
Numbers
RLH-2404-1BP
RLH-2404-1RB
Ordering
24VDC 4.5Ah DIN Mount Battery Pack (legacy)
